ADT's 25th Anniversary & User Group Meeting

15th -16th November 2023 - Red Bull Racing MK-7 Venue

Keynote

Chair: Prof. Mehrdad Zangeneh

09:30 – 10:00

Designing next-generation power units for F1’s sustainable future

Red Bull Ford Powertrains is designing and building the new power unit – engine, turbocharger and hybrid system – for the 2026 F1 season, which ushers in a new hybrid engine design and sustainable fuel requirements. While the team now has a working prototype of the 2026 engine, there are many design iterations and further developments yet to come before its descendants hit the track. And with Oracle Red Bull Racing, the defending champion team of the 2023 F1 Championship, there’s only one ultimate measure of success: The top spot on the driver and team rankings.

Confirmed-speakers--logos-red-bull-powertrains-ugm2023

Ben Hodgkinson (Red Bull Ford Powertrains, UK)

Technical Director

Session 5 - Fan

Chair: Dr. Jiangnan Zhang

10:00 - 10:30

Correlation between TD1’s acoustic parameters and measurements on physical prototypes

The acoustic performance of fans is of prime importance to meet customers’ needs. However, acoustics is hard to simulate, and insight is primarily gained via measurements of prototypes. That makes methods for noise estimation at an early design stage very interesting. We show in this contribution how the TD1 acoustic output parameters correlate with measurements.

Dr. Benoît André (ebm-papst St. Georgen GmbH & Co. KG, Germany)

R&D Engineer Fluid Mechanics - Air Technology Europe, R&D Compact Air Technology

10:30 - 11:00

Optimization of Greenheck fan products using ADT's Inverse Design methodology

Greenheck has a diverse product line and often designs fan products and systems using basic turbo-machinery principles and 2D techniques. However, ADT's 3D inverse design method has been used effectively for the past 5 years to develop axial, mixed flow, and centrifugal fans for a variety of HVAC applications. The presentation focuses on how Greenheck was able to achieve high static efficiency in less time, particularly for retrofit and data center applications. The presentation also discusses how Greenheck used ADT to produce customer-centric design choices (cost vs. efficiency) for a single application.

Dr. Vijaya Kumar Kollipara, PhD. (Greenheck Group, USA)

Principal R&D Engineer - Advanced Materials and Engineering Department

11:00 - 11:30

Refreshment Break and Networking

Session 6 - TURBOdesign2 and Novel Applications

Chair: Lorenzo Bossi

11:30 - 12:00

Controlling cavitating flow and cavitation erosion aggressiveness using Inverse Design method

The inverse design technology to control cavitation flow and cavitation aggressiveness will be introduced. By using the technology, loading distribution of a blade under conditions where cavitation occurs can be controlled. The effects of loading distribution and experimental validations will be discussed in the presentation.

Dr. Hiroyoshi Watanabe, Ph.D. (Ebara Corporation, Japan)

General Manager, Technology Development Division - Building Service & Industrial Company

12:00 - 12:30

Shock control in transonic axial compressors by TURBOdesign2

Dr. Luying Zhang

Principal Turbomachinery Design Engineer at Advanced Design Technology, Ltd.

12:30 - 13:30

Lunch and Networking

Session 7 - Historical Perspectives and Roadmap development

Chair: Dr. Akira Goto

13:30 - 14:00

Historical perspectives on development of TURBOdesign

Prof. Mehrdad Zangeneh

Co-founder and Managing Director, ADT

14:00 - 14:30

Automation, machine learning and future roadmap for TURBOdesign Suite

Prof. Mehrdad Zangeneh

Co-founder and Managing Director, ADT

14:30 - 14:45

Refreshment Break and Networking

Session 8 - Pumped Hydro Storage Applications

Chair: Dr. Luying Zhang

14:45 - 15:15

Optimization design of pump-turbine runner using ADT's TURBOdesign

The fully three-dimensional inverse design tool TURBOdesign is used in optimization design of the pump-turbine runners in order to satisfy the multiple requirements for the pump-turbines. Some important performances based on the experimental measurements and the numerical simulations are presented.

Prof. Baoshan Zhu (Tsinghua University, P.R. China)

Professor of Department of Energy and Power Engineering

15:15 - 15:45

Multi-point optimization of contra-rotating reversible pump turbine for low head energy storage applications - ALPHEUS

Widespread adoption of renewable energy sources such as solar and wind power calls for supplementary green technologies such as Pumped Hydro Storage (PHS) systems for stabilizing a grid because of the intermittent nature of the former. Traditionally hydro power systems are designed for high head operation and hence the potential installation sites are limited. Low head PHS systems are desirable for flat geographies where high head reservoirs are not possible. Development of such a system for augmenting grid stability is the aim of ALPHEUS project funded by the European Union’s Horizon 2020 program. To meet the challenges, a shaft driven contra-rotating reversible pump turbine is designed using inverse 3D blade design approach. CFD analysis is performed in both pump and turbine modes of operation to assess the performance across a range of conditions. An optimization is carried out in the model scale using a Design of Experiments approach to maximize the performance.

Melvin Joseph (Advanced Design Technology Ltd)

Senior Turbomachinery Design Engineer

Closing Remarks

15:45

Prof. Mehrdad Zangeneh

Co-founder and Managing Director, ADT

16:00
