Optimizing Volute and Scroll Geometries

Unique 2D inverse design method for volutes and scrolls that outputs solid IGES files in minutes ready for CFD computations.

AnyConv.com__Volute Intro

Design Your Volute to Automatically Match Your Impeller Outlet Flow

TURBOdesign Volute automatically computes the the correct volute circumferential area distribution matching your impeller flow field.

AnyConv.com__2D Inverse Design - Volute slide 26

Design All Types of Volutes

Design symmetric, asymmetric, overhung volutes with tangential or radial exit for compressors, pumps, turbines and fans.

AnyConv.com__Optimization of Volute Designs

Optimization of Volutes Design

Enables designing volutes with circumferential variation of inlet velocity and flow angles resulting in unconventional area variations.

AnyConv.com__Slide 28 bis

Any Cross Section Shapes Can Be Designed

The TURBOdesign Volute tool allows the choice of various standard cross-section shapes and arbitrary cross-sections by using B-spline.
